Manual Reset Circuit Breaker 20 30 40 50 AMP Stud Bolt Type Dual Battery Fuse 14-28V For Car Boat Truck
$5.76
- Product Code: ED0009588
- Availability: In Stock
- Ex Tax: $5.76
Available Options
Feature:
1.Overcurrent circuit breaker, using bimetal structures, when the circuit is overloaded, quickly power protection.
2.Rubber protective cover protect terminals from moisture, dust and accidental shorting.
3.Black UL rate 94V0 thermoplastic body with gray cover thermoplastic.
4.One copper post and one plated terminal.
5.Plastic with parallel mounting bracket.
6.For Battery chargers, auto , trucks, buses, RVs, trolling motors, etc.
Specification:
Product Name |
Manual Reset Breaker |
Model |
F3088 |
Rated Current |
20A, 30A, 40A, 50A (Optional) |
Working Voltage |
12-28V DC |
Interrupt Rating |
2.5KA @ 12V DC |
Operating Temperature |
- 40F - 185F (- 40c - 85c) |
Waterproof Rating |
IP66 |
Size |
5.1*2.1cm / 2*0.82inch |
Material |
Metal + Plastic |
Connection |
Gold head BAT (Inlet), Silver head AUX (Outlet) |
Packing Included:
1 X Manual Reset Breaker
