Feature:
1.Gravity sensor function.
When the gravity acceleration starts,the machine will automatically save the video when the accident occured was not delete the file.
2.File locking feature.
The imaging process,the M key is pressed,the machine will not delete the current video us saved as a file.
3.Parking guard function.
-Parking guards opened,when the vehicle stalled,tachograph into the automatic shutdown procedures,
if you receive external vibration generated by the tachograph will open the camera,automatically shutdown after a record 10-15 seconds;
if you receive external vibration generated by the tachograph will open the camera,automatically shutdown after a record 10-15 seconds;
when the body is detected again after the shock,again start camera function.
-Parking for guarding video camera 1080P 30 frames/sec,and the file is automatically locked.
Note:
The parking guard function must only work in the case of tachograph automatic shutdown,
manual startup or shutdown,the parking guard does not work.
The parking guard function must only work in the case of tachograph automatic shutdown,
manual startup or shutdown,the parking guard does not work.
4.Motion detection function.
Turn on the motion detection function,the camera would start recording after short pressing the OK button.It would turn to the motion detection standby state after 10 seconds recording,this time ther is flashing yellow spot on the upper left corner of the screen.
When detecting the movement,the recorder will start recording automatically, the yellow flashing spot turn to red flashing spot at the mean time.
It will start recording again when detecting the movement motion.
5.USB mode.
Connect the USB cable to the computer,tachograph will automatically eject the USB manual will appear the following options.
-Memory.In this mode,the video file can be accessed,or photo files.
-Camera.Select this mode will bring up the USB video device, can be real-time network camera or video chat as a PC camera.
6.The battery instruction.
After connection the car charger power, the red charging indicator light will light up during the charging time,it would usually takes 180 minutes.
The red charging indicator light will off automatically when the charging is done.
Note:
The built-in battery was designed for saving the file while parking off,for saving the battery life, we are generally suggested you should connect
the car charger in daily use.
7.Reset.
You could reset the machine whenever it broke down or something happened.
Package Included:
1 X Car Recorder | 1 X Adhesive Buckle |
1 X Car Charger | 1 X USB |
1 X Video Decompression Cable | 1 X User Manual |
Specificaiton:
Pixel | 100 million |
Lens Angle | 140 degree |
Resolution |
1920x1080 25FPS
1080x720 30fps
|
G-sensor | Support |
Display Screen |
3.0 inch 16:9 960x240 |
Loop Recording | Support |
Parking Guard | Support |
Motion Detection | Support |
Infrared | Support |
Night Vision | Support |
Compressed Format | M-JPEG |
Storage Card | TF Card,maximum 32G |
Power Interface | DC 5V-700mA |
Battery | Built-in 180mAh |
Output | AV-OUT |
Microphone | Support |
Stereo | Support |
Current Frequency | 50/60HZ |
Language | English,Russian,Korean,Simplified Chinese,Traditional Chinese,Janpanese,French,German,Italian,Spain,Thai etc. |
Specificaiton:
Pixel | 100 million |
Lens Angle | 140 degree |
Resolution |
1920x1080 25FPS
1080x720 30fps
|
G-sensor | Support |
Display Screen |
3.0 inch 16:9 960x240 |
Loop Recording | Support |
Parking Guard | Support |
Motion Detection | Support |
Infrared | Support |
Night Vision | Support |
Compressed Format | M-JPEG |
Storage Card | TF Card,maximum 32G |
Power Interface | DC 5V-700mA |
Battery | Built-in 180mAh |
Output | AV-OUT |
Microphone | Support |
Stereo | Support |
Current Frequency | 50/60HZ |
Language | English,Russian,Korean,Simplified Chinese,Traditional Chinese,Janpanese,French,German,Italian,Spain,Thai etc. |
